building facade, balustrate, curtain wall, skylight,podium
EN12150, SGCC, ISO,AS/NZS
50000 Square Meter/Square Meters per Day
Packaging & Delivery
Wooden crate with protection film
FOBShenzhen or any other Chinese port
1 - 1000
To be negotiated
It’s made of two or more than two sheets of glass between which one or multi-layers of PVB with strong cohesion is sandwiched under high tempered and pressure.
1.Safety: When laminated glass is attacked by outside force, it hard to be penetrated because PVB film has strong tenacity and can absorb and weaken a mass of striking energy. Even if it’s broken, the splinters will stick to the interlayer and not scatter.
2.Sound Insulation: PVB film can effectively prevent sound wave.
3.Anti-UV: Laminated glass can effectively present UV.
4.Security: It’s impossible to cut the laminated glass with glass cutter, therefore, laminated glass has strong resistance function to evil destruction.
Application: building window and door, high grade curtain wall, lighting, skylight, elevated floor, furniture, showcase, counter, automotive glass and aquarium etc.
Max Size: 3300*16000mm
Min Size: any
sole glass thickness: 3mm-25mm
Film thickness: 0.38mm and multiple of 0.38mm
In accordance with GB9962-1999
In accordance with ASTM Standard;
In accordance with BS Standard;
In accordance with AS/NZS Standard;
In accordance with CE Standard;
In accordance with ISO Standard;
Pass Chinese Safety Glass Compulsory Certification(CCC)
Packing & Delivery
Shenzhen Dayang Special Glass Co.Ltd., located in Shenzhen China (Nearby Hongkong), has 5 big factories with a floor space of 400 acre. Dayang has been always applying ourselves to the design, R&D, manufacture and sales of all-kinds of deep-processing glass, well known as a leading glass manufacture in and abroad.
Products include Energy-saving glass, curved glass, smart glass, art glass, complex glass and furniture glass. The company has many patent on the smart glass and art glass which is highly reputed from all our clients!
Q1: How to judge the quality of float glass? A1: Flatness, transparency, colorless, impurities, bubbles, etc.
Q2: How to reduce the self-implosion? A2: The high quality float method is used for hot dip treatment, edge treatment and proper stress intensity. Pay attention to avoid side collision of glass during installation.
Q3: Scope of use of toughened glass? A3: Safety is not involved in some parts of the building, but it is necessary to install toughened glass to improve the compressive strength and explosion-proof capacity, and not to endanger the safety of the person.
Q4: When toughened glass is broken, is the grain smaller the better? A4: No, the smaller the particle, the easier it is to explode.
Q5: Can toughened glass and semi-toughened glass be made into laminated glass? A5: Can't. The national standard stipulates: the glass that stresses the difference cannot make laminated glass, because in use process, the pressure that two pieces of glass bears is different.
Q6: Whether the laminated glass can fire, can the sound insulation? A6: No, the smaller the particle, the easier it is to explode.
Q7: How many uv low-e glass can reduce? A7: It is not fireproof glass, but has certain fireproof ability, also can soundproof, laminated glass is inside whole sound wave frequency range, in control noise is very good.
Q8: Does the air in the insulating glass do not oxidize the membrane? A8: No, because there is a molecular sieve in the insulating glass, and the molecular sieve always keeps the air dry, so the membrane is not oxidized.
Q9: How much ultraviolet radiation can low-e glass reduce? A9: It can reduce uv by 14% compared to heat reflecting glass. That's a 25 percent reduction in uv radiation compared to white glass.
