Professional Shipping Container Spare Parts Supplier

FOB Reference Price:Get Latest Price
$1.50 - $3.00 / Kilogram | 1 Kilogram/Kilograms (Min. Order)
Samples:
$3.00 /Kilogram | 1 Kilogram (Min. Order) | Buy Samples
Lead Time:
Quantity(Kilograms) 1 - 200 >200
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Type:
Container Parts
Name:
shipping container spare parts
Floor Material:
Hard wood
Structure Material:
Corten steel
Corner casting:
SCW480
Door Rubber:
EPDM
Full set of Container parts:
20ft 40ft GP or HC
Brand Name:
ACE
Use for:
Shipping Container
Surface Treatment:
Galvanized
Port:
Shanghai, Ningbo, Tianjin
Supply Ability
Supply Ability:
10000 Kilogram/Kilograms per Month container spare parts
Packaging & Delivery
Packaging Details
shipping container spare parts, wooden cases or as per your request
Port
Tianjin, ShangHai, ShenZhen, GuangZhou
Lead Time :
Quantity(Kilograms) 1 - 200 >200
Est. Time(days) 15 To be negotiated
Hot Sale Products
ISO1161 Container Corner Fitting
Container Door Locking Parts
Container Door Hinge
28mm Container Plywood
EPDM Container Door Gasket
Corten Steel Container Roof Panel
Product Description

Shipping Container Spare Parts

ACE is a professional Container Parts supplier in China, have been this line for over 10 years, and exported our products to over 55 countries. The parts we supplied is high quality with good price.

We could supply all kinds of container parts, including roof panel, side panel, side rail, top rail, locking parts, corner casting, gasket, hinge set etc. You could order them separately or mix them together.


Why choose ACE?

1.ACE provide full range of ISO container parts with good quality and reasonable price.
2.ACE have exported ISO dry container parts to Over 55 Countries.
3.ACE are the No. 1 Seller of container parts.

4. Mixed order is also no problem
5. Fast reply and offer are our one of advantage.
6. One-Stop Purchasing is also our big advantage.


Detailed Shipping Container Parts List:

Other Parts
DESCRIPTION
Dimensions(mm)
Material









Door End
ISO Corner Fitting, 8pcs/set
178x162x118
SCW480
Door Hinge Set
Blade, Pin, Lug, Bush
Container Door Locking Device
Door Gaskets
1143x2254
EPDM
Gasket Retainer
SUS304
CSC plate
0.8x100x200
SUS304
Door Panel (3 CORR)
2.0X943X1957
CORTEN
Door Vertical Member Edge SQ.Tube
3.2x50x100x2260
CORTEN
Door Horizontal Member Edge, Channel
3.0x50x150x1024 or 943
CORTEN
Door Sill
4.5x158x150x2400
CORTEN
Door Header Lower
4.0x112.5x113x137.5x2400
CORTEN
Rear Corner Post inner
12x113x40x2353
CORTEN
Rear Corner Post outer
6.0x70x39x230x2400
CORTEN


Front End
Front End Panel
2.0x1024x2400
CORTEN
Front Corner Post
6.0x209x225x2400
CORTEN
Front Bottom Rail
4.0X115X154x2400
CORTEN
Top End Member SQ.Tube (Horizontal)
3.0x60x60x2112
CORTEN
Roof
Container Roof Panel (5 CORR)
2.0x1045x2356
CORTEN
Door Header Upper (Extension Plate)
3.0x388x2400
CORTEN
Top End Rail (Extension Plate)
3.0X397x2400
CORTEN
Side
Container Side Panel
1.6x1116x2400
CORTEN
Top Side Rail, SQ. Tube
3.0x60x60x5702
CORTEN
Ventilator Cover
204x67x25
ABS





Base
Container Plywood Flooring, 19ply
28x1160x2400
Hardwood
Floor screw
L=5 to 120
CORTEN
Bottom Side Rail
4.5x50x162x30x5702
CORTEN
Cross Member Small
4x45x122x45x2350
CORTEN
Cross Member Large
4x45x122x75x2350
CORTEN
Fork Pocket Bottom Plate
360x300
CORTEN
Fork Pocket Top Plate
360x2350
CORTEN
Gooseneck parts
CORTEN




Other
Lashing Ring
SS41
Hexagon Set screws Nuts and Bolts
L=6 to 200
CORTEN
Sealed pop rivet Blind rivet
4.8*16.5
CORTEN
Decals: Weight& Capacity, UIC, Container Type, Ower's Serious
CORTEN
Open Top Container: Header Hinge,Tarpaulin, Eyelet,TIR Cable, D-Ring
Flat Rack: Twistlocks
Detailed Images
Packing & Delivery

Container Spare Parts Packing and Loading:

All container spare parts are packed into pallet and pallet box.

Corner Casting: Exported Pallet. 100 pcs into one pallet, 20 pallet into one 20ft container.

Door Lock Parts: Steel Pallet, 200 sets into one pallet.

Plywood: 30 pcs into one pallet, 8 pallets into one 20ft container.

For other container steel structure parts, you could order them in mixture, usually 25 tons of parts loaded into one 20ft container.

Our Company

ACE Container & Parts Co., Ltd.

We are very famous and professional Container and Parts supplier in China, and have been container line for over 10 years, also have exported our product to 80 countries by the end of 2017, including Japan, Korea, Southeast Asia, North and South America, Africa etc.

With the increment of requirement for offshore equipment, ACE Container & Parts also arrange offshore equipment production for Oil and Gas platform as per you customized requirement, all of them are design as per DNV2.7-1 & EN12079 standard.

Main Products: ISO Dry Container, Reefer Container, Offshore Equipment, All kinds of Container Parts and Customized Special Container

FAQ
1. Are your shipping container spare parts good quality?
Yes, all of our containers are ABS, BV, GL, CCS Certificate. If our parts are not good, our container won't be good. How can we pass the ABS, BV, GL, CCS testing.

2. Can we order mixed parts?
Sure, you could order.

3. Any surface treatment for your shipping container spare parts?
Yes, with zinc rich primer coating or Galvanized.

4. Can i order a container to load our container spare parts?
Yes, that will be good, this may save your cost in port. We have rich experience to operate SOC shipment, also often do it like this.
